GE MVP11 369B1848G5004 Valve Position Control Module

GE MVP11 369B1848G5004 Valve Position Control Module

The MVP11 is a Valve Position Control Module, manufactured and designed by General Electric as part of OC 6000e series used in Distributed Control System.

Features

• Power input: 24 VDC

• Control cycle: < 10 ms

• Control signals: 0 - +/- 10, 40, 80, 250, 400 mA, +/- 10 VDC

• Feedback signal: 0-20 mA, ±10 V DC, LVDT, RLVDT

• DI:

Channel: 2

On-state: 15-30 V / 2-5.5 mA

Off-state: 0-5 V / 0-0.5 mA

• DO:

Channel: 1

Output relay status: NO

Relay capacity: 220 VAC/VDC

Contact type: wet/dry

•AI:

Channel: 2

Signal: +/- 10 VDC, 0-20 mA

•AO:

Channel: 2

Output: 0-5 VDC

•LVDT:

Channel: 2

Accuracy: 0.25%

•Servo out:

Channel: 2

Accuracy: 0.2%

Current: +/- 400 mA

Technical Specifications
