IS200JPDSG1ACB Power Distribution Board

The IS200JPDSG1ACB is a Power Distribution Board, manufactured and designed by General Electric as part of the Mark VIe Series used in the GE Speedtronic Control System.

The 28 V Power Distribution (JPDS) board receives 28 V dc input power from external ac/dc or dc/dc converters and distributes power to the control system. JPDS integrates into the PDM system feedback offered through the PPDA I/O pack.

Compatibility:

The IS200JPDS board is compatible with the feedback signal P1/P2 connectors on JPDB, JPDF, and JPDE leading to a PPDA I/O pack. The DC-62 connector on JPDS is compatible with the IS220PPDA I/O pack.

Installation:

JPDS mounts in a metal holder, which fits on a vertical DIN-rail next to other power distribution boards. Optionally, JPDS is also available with a metal holder designed for direct mounting. Refer to the wiring diagrams for power input and output routing. There is a 50-pin diagnostic connector mounted on the top and bottom of the board.

Grounding:

The IS200JPDSG1ACS board is grounded through the sheet metal bracket to the underlying back base. In most cases, this can be the system FE.
