The CP502 is a dynamic pressure transducer, it is ideally suited for high-temperature applications such as:
• GT closed loop combustion control (emissions reduction)
• GT control during critical transient phases
Brand :
VMPart number :
CP502 143-502-000-061Description :
Piezoelectric Pressure TransducerOrigin :
SwitzerlandCondition :
NewDimension :
38.8 mm x 11 mm x 11 mmWeight :
0.2 kgPayment :
Bank Transfer
CP502 143-502-000-061 Piezoelectric Pressure Transducer
Functional Description
The use of piezoelectric single-crystal in the CP 502 dynamic pressure transducer makes it an extremely
stable and reliable device.
The transducer is applicable to either long-term monitoring of pressure pulsation in gas turbines or
development testing.
The industrial-grown single-crystal GaPO4 guarantees excellent signal quality and constant sensitivity.
It is fitted with an integral mineral insulated cable (twin conductors) which is terminated with a LEMO
connector.
Features
· Designed for use in gas turbines
· Temperature range : -70 ºC to 560 ºC (-94 °F to 1050 °F)
· Outstanding thermal behaviour (no pyroelectricity)
· Sensitivity virtually constant over product lifetime
· Very low response threshold
· Internal case insulation
Technical Specifications
| Manufacturer | VM |
| Part Number | CP502 143-502-000-061 |
| Ordering Information | CP502 143-502-000-061 |
| Product Catalog | Vibration Monitoring |
| Description | Piezoelectric Pressure Transducer |
| Voltage | 24 Vdc |
| Current | 1 A |
| Dimensions | 38.8 mm x 11 mm x 11 mm |
| Weight | 0.2 kg |
