The AI801 Analog Input Module has 8 channels for current input. The current input is able to handle a short circuit to the transmitter supply at least 30 V d.c without damage.US$600.00
Brand :
ABBPart number :
AI01Description :
Analog Input ModuleOrigin :
IndiaCondition :
NewDimension :
51 mm x 190 mm x 138 mmWeight :
0.4 kgPayment :
Bank Transfer
ABB AI01 Analog Input Module
The AI01 analog input module processes up to 16 analog field inputs. Field inputs are isolated into two groups of eight. Each input channel can be individually programmed for:
– 4 to 20 mA
– 1 to 5 VDC
– 0 to 5 VDC
– 0 to 10 VDC
– 10 to +10 VDC
The AI01 can be used with either HBS01-FPH or HBS01-EPD bases.
Current limiting is performed with a PTC resistor. The input resistance of the current input is 250 ohm, PTC included.
|
Power requirements
|
24 VDC +12%, -10% at 75 mA typical, 84 mA max.
|
|
Analog input channels
|
16 independently configured channels
|
|
- Current
|
4 to 20 mA
|
|
- Voltage
|
1 to 5 VDC
|
|
A/D Conversion
|
1 A/D converter per group, 8 inputs per group
|
|
- Resolution
|
16 bits with polarity
|
|
- Conversion time
|
22.5 ms per configured input; 180 ms if all channels
are configured
|
|
Ambient temperature
|
-20 °C to 70 °C (-4 °F to 158 °F). Tested according
to IEC/EN 60068-2-1, IEC/EN 60068-2-2
|
|
Service port
|
1 mini-USB port
|
|
Dimensions (with base)
|
51mm width, 190 mm height, 138 mm depth
( 2 in. width, 7.48 in. height, 5.43 in. depth)
|
|
Weight
|
0.4 kg |
