The LD 810HSE Ex is a gateway between an FF High Speed Ethernet (FF-HSE) subnet and FF-H1 links. It supports device redundancy. The Linking Device meets protection class IP20 and is DIN rack mountable. It is powered by 24 V DC and supports Ethernet 10 Mbit/s or 100 Mbit/s.

The LD 810HSE Ex is registered as class 42c of the HSE profile, therefore providing the following functions:

– It supports up to 4 separate FF-H1 links. In each of these links, the Linking Device operates as Link Master as well as SM Time Publisher.

– Identification of devices connected to the H1 links

– Configuration of connected H1 devices through System Management and Network Management via HSE

– Access to the function blocks of connected H1 devices via HSE

– Republishing of process data between H1 links

– Republishing of process data from H1 to HSE and vice versa

– Distribution of alarms and events sent by H1 devices

Gateway

• Identification of devices connected to the H1 links

• Configuration of connected H1 devices through System Management and Network Management via HSE

• Access to the function blocks of connected H1 devices via HSE

• Republishing of process data between H1 links

• Republishing of process data from H1 to HSE and vice versa

• Distribution of alarms and events sent by H1 devices

• It supports up to 4 separate FF-H1 links

HSE

• System Management Agent

• Network Management Agent

• FMS Server providing object access to H1 devices

• Publishing/subscribing of process data from/to H1 devices

• Simple Network Time Protocol (SNTP) Server according to HSE specification (SM time synchronization)

• Simple Network Management Protocol (SNMP) is not supported

• Maintenance functions via web server

• Firmware update of Linking Device and H1 power supply modules via http or https
